| Size/Weight |
| Dimensions |
Width |
149 cm (59") |
| Height |
101 cm (40") |
| Depth |
186 cm (6'1") |
| Weight |
Weight |
341 kg (750 lb) |
| Control Interface |
| Keyboard |
Key Surfaces - White |
Ivorite |
| Key Surfaces - Black |
WPC |
| Hammer |
Type |
CX Series Special |
| Pedal |
Type |
Damper/Sostenuto/Shift |
| Design/Architecture Detail |
| Caster |
Type |
Single Caster |
| Cabinet |
| Lid |
Prop Safety Stop |
Yes |
| Key Cover |
Lid/Fallboard Locks |
Yes |
| Soft-Close Fallboard |
Yes |
| Sensor System |
| Key Sensors |
Non-contact continuous detection optical sensor |
| Hammer Sensors |
Non-contact 2-point optical fiber sensor |
| Damper Pedal |
Continuous detection sensor |
| Sostenuto Pedal |
On/Off detection sensor |
| Soft/Shift Pedal |
On/Off detection sensor |
| Silencing System |
| Mechanism |
Hammer shank stopper operated by motor drive |
| Action |
Quick Escape mechanism |
| Soundbord Drive System |
| Mechanism |
TransAcoustic™ technology |
| Voices |
| Tone Generation |
Piano Sound |
Yamaha CFX |
| Binaural Sampling |
Yes (CFX Grand Voice only) |
| String Resonance |
Yes |
| Damper Resonance |
Yes |
| Sustain Samples |
Yes |
| Key-off Samples |
Yes |
| Polyphony (max.) |
256 |
| Preset |
Number of Voices |
19 |
| Voices for Song Playback |
480 XG Voices + 12 Drum/SFX Kits |
| Effects |
| Types |
Reverb |
Yes |
| Brilliance |
Yes |
| Songs (MIDI) |
| Preset |
Number of Preset Songs |
3 Piano demonstrations, 50 greats for Piano |
| Recording |
Number of Songs |
10 |
| Data Capacity |
approx. 550 KB/Song |
| Format |
Playback |
SMF (Format 0, Format 1) |
| Recording |
SMF (Format 0) |
| Recording/Playback (Audio) |
| Recording Time (max.) |
80 minutes/Song |
| Format |
Playback |
WAV (44.1 kHz, 16 bit, stereo) |
| Recording |
WAV (44.1 kHz, 16 bit, stereo) |
| Functions |
| Overall Controls |
Metronome |
Yes |
| Tempo Range |
5 – 500 |
| Transpose |
-12 – 0 – +12 |
| Tuning |
414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments) |
| Storage and Connectivity |
| Storage |
External Drives |
USB flash drive |
| Connectivity |
Headphones |
Stereo mini jack (x2) |
| MIDI |
IN/OUT |
| AUX IN |
Stereo mini jack |
| AUX OUT |
Stereo mini jack |
| Speaker Output |
Phone Jack x 2 |
| USB TO DEVICE |
Yes |
| Power Supply |
| Power Consumption |
44 W |
| Auto Power Off |
Yes |
| Accessories |
| Included Accessories |
Headphones, Headphone hanger, Attachment screws for headphones hanger, “50 greats for the Piano” music book, Owner’s manual. |
